    45° / 0° SCE 3nh Spectrophotometer 400nm - 700nm Wavelength For Paints


    45°/0° SCE 400nm-700nm Wavelength 3nh NS800 Spectrophotometer with 200% Reflectance


    NS800 portable spectrophotometer for measuring the color difference standard and sample measured, the measuring geometry 45°/0°, high accuracy and repeatability of measurements. Recommended wherever measurement is required in accordance with the visual impression, f.ex. quality control of party products. With its lightweight, a large internal memory and use rechargeable batteries measurements can be made at any stage of production, anywhere. NS800 spectrophotometer equipped with a 3.5 "color touch-screen - easy to use with intuitive menus. It has the ability to connect to computer via USB.


    Especially recommended for measuring vehicle cabin interior components, reflective elements, etc. Of electronic components, paints and varnishes. It can be used in the pharmaceutical and cosmetic industries.


    ModelNS800 Spectrophotometer
    Lighting/measurement system45°/0°, SCE
    DetectorSilicon photodiode
    Diameter integrating sphereΦ58mm
    Measurement rangeReflectance: 0 to 200%
    Wavelength range400nm-700nm
    Spectral resolution10nm
    ObserverCIE: 2° i 10°
    Measuring apertureΦ8mm
    IlluminantCIE D65, A, C, D50, D55, D75, F2, F6,F7, F8, F10, F11, F12
    Measurement functionCIE LAB, XYZ, Yxy, LCh, CIE LUV; ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00;
    White Index(ASTM E313, CIE/ISO,AATCC,Hunter), Yellow Index(ASTM D1925, ASTM 313), TI(ASTM E313, CIE/ISO), metamerism index (Mt), greyscale
    RepeatabilityMeasurement conditions: white calibration plate measured 30 times at intervals of 5 sec.,
    after calibration white reflectance standard deviation of 0.1% (400 ~ 700nm: within 0.2%)
    chromaticity value: the standard deviation ΔE * ab 0.04.
    Conformity between instrumentsΔE * ab within 0.2 (measurement conditions: the average for the 12 color plates BCRA Series II compared to values measured with the reference device)
    Measurement memory1000 measurements of models, 10000 measurements of samples
    Power sourceRechargeable Li-ion battery, AC power cord
    Dimensions and weightLxWxH=90x77x230mm; 600g
    Work conditions0 ° C - 40 ° C, relative humidity of 80% or less (at 35 ° C)
    Additional accessoriesMiniature printer, adapter for measuring liquids, pastes and powders
    Additional informationsCompliance with CIE No.15, Includes: black and white calibration plate, shell panel,
    Li-ion battery, power cable, software CD

    45°/0° SCE 400nm-700nm Wavelength 3nh NS800 Spectrophotometer with 200% Reflectance
