8mm Aperture Paint Spectrophotometer Equipment 3NY YS3010 With Pantone Softwar

Ask Lasest Price
Brand Name :	3nh
Model Number :	YS3010
Certification :	CE, TUV, FCC, RoHS, ISO9001
Price :	Please send inquiry
Payment Terms :	T/T
Supply Ability :	500 Units per Month
Delivery Time :	2-5 Days

Add to Cart

Product Details
Company Profile

8mm Aperture Paint Spectrophotometer Equipment 3NY YS3010 With Pantone Softwar

YS3010 spectrometer

Wood look rubber flooring color testing equipment manufacturer of 3nh brand portable spectrophotometer ys3010

YS30 Series grating spectrophotometer adopts bluetooth and USB dual modes for wider use, and with SCI & SCE measurement data, it is compatible with many famous brands. 8mm, 4mm or customized aperture is optional. Speical UV light makes YS3060 easy to measure sample with UV and high accuracy and extended function PC software let it be good partner for colorist and color quality contral management.

YS3060 UV Grating Spectrophotometer

Full Illuminants + UV, 8mm&4mm Apertures, SCI&SCE, Bluetooth Comm, High Precision.

YS3020 Grating Spectrophotometer

Multi-illuminants, Customizable Aperture, SCI&SCE, Bluetooth Comm, High Precision.

YS3010 Grating Spectrophotometer

4 Illuminants, 8mm Aperture, SCI&SCE, Good Precision.

Comply with CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724/1,ASTM E1164,DIN5033 Teil7, YS3060 grating spectrophotometer features UV, SCI/SCE, USB / bluetooth, 8mm / 4mm switch aperture, etc. It has high accuracy 0.03 based on white calibration plate measured 30 times at 5 seconds intervals after white calibration was performed.

Product Application

Grating spectrophotometer can easily achieve color transferring , and be used as a precision instrument for color matching system. It's widely used in plastics, electronics, painting, ink, textile and garment, printing and dyeing, printing paper, automotive, medical, cosmetics and food industries, scientific research institutes, schools and laboratories.

SPECIFICATIONS FOR YS3060 & YS3020 & YS3010 Spectrophotometer
Model Items	YS3060	YS3020	YS3010
Optical Geometry	Reflect: di:8°, de:8°(diffused illumination, 8-degree viewing angle)
Integrating Sphere Size	48mm
Light Source	Combined LED Light, UV Light	Combined LED Light
Spectrophotometric Mode	Concave Grating
Sensor	256 Image Element Double Array CMOS Image Sensor
Wavelength Range	400-700nm
Wavelength Interval	10nm
Semiband Width	10nm
Measured Reflectance Range	10nm
Measured Reflectance Range	0-200%
Measuring Aperture	MAV : Φ8mm/Φ10mm SAV : Φ4mm/Φ5mm	Customized Aperture: 8mm/4mm/1×3mm	Single Aperture: MAV : Φ8mm/Φ10mm
Specular Component	SCI&SCE
Color Space	CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB
Color Difference Formula	ΔEab, ΔEuv, ΔE94, ΔEcmc(2:1), ΔEcmc(1:1), ΔE00v, ΔE(Hunter)
Other Colorimetric Index	WI(ASTM E313, CIE/ISO, AATCC, Hunter), YI(ASTM D1925, ASTM 313),TI(ASTM E313, CIE/ISO), Metamerism Index MI, Staining Fastness, Color Fastness, Color Strength, Opacity, 8° Glossiness
Observer Angle	2°/10°
Illuminant	D65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12	D65, A, C, D50, D55, D75, F2, F7, F11	D65, A, C, D50
Display Data	Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset
Measuring Time	2.6s
Repeatability	MAV/SCI: ΔE*≤0.03	MAV/SCI: ΔE*≤0.05	MAV/SCI: ΔE*≤0.06
Inter-instrument Error	MAV/SCI: ΔE*≤0.15	MAV/SCI: ΔE*≤0.2	MAV/SCI: ΔE*≤0.4
Measurement Mode	Single Measurement, Average Measurement
Locating Method	Camera View Finder Locating
Battery	Li-ion battery. 5000 measurements within 8 hours
Dimension	LWH=18477105mm
Weight	600g
Illuminant Life Span	5 years, more than 3 million times measurements
Display	3.5-inch TFT color LCD, Capacitive Touch Screen
Data Port	USB, Bluetooth 4.0		USB
Data Storage	Standard 2000 Pcs, Sample 20000 Pcs
Language	English, Chinese
Operating Environment	0~40℃, 0~85%RH (no condensing), Altitude < 2000m
Storage Environment	-20~50℃, 0~85%RH (no condensing)
Standard Accessory	Power Adapter, Built-In Li-ion Battery, User Guide, PC Software, White and Black Calibration Cavity, Dust Cover
Optional Accessory	Micro Printer, Powder Test Box
Notes: The specifications are subject to change without notice.

Main Features

A.Perfect combination of beautiful appearance and the human body mechanics structural design;
B.D/8 geometrical optics, conforms with CIE No.15,GB/T 3978,GB2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil
C.Use long life and low power consumption combined LED light source, including UV/excluding UV;
D.Switchable Φ8/4mm aperture, adapt to more samples; support both SCI and SCE at the same time;
E.Measure sample spectra, accurate Lab data , can be used in color matching and accurate color transmission;
F.High electronic hardware configuration: 3.5-inch TFT color LCD,Capacitive Touch Screen, concave grating, 256 Iimage Element Double Arrays CMOS Image Sensor;
G.USB/Bluetooth 2.1, dual mode, widely useful;
H.Super stain-resistant and stable standard white calibration plate;
I.Large capacity storage space, over 20,000 measurement data;
J.Two standard observer angles, a variety of illuminant, a variety of color indexes, conforms with a variety of standard colorimetric data, meet a variety of customers' demand for color measurement;
K.Camera Locating Function, better position;
l.PC software has a powerful function extension.

Packing & Delivery

Packing Details : Carton package

Delivery Details : within 2 days after payment

Payment Terms: T/T 100% In Advance

Certifications

8mm Aperture Paint Spectrophotometer Equipment 3NY YS3010 With Pantone Softwar

About us

Shenzhen 3nh Technology Co., Ltd, is a high-tech enterprise. We research, develop, produce and market photoelectric detection products in photoelectric detection technology field and color management field.

Shenzhen 3nh Technology Co., Ltd. and Shenzhen TILO Technology Co., Ltd are from the same boss, we work together in one office.

We produced colorimeter, spectrophotometer, color light box and gloss meter, iso 12233 test charts, and we offer OEM service and supply all kinds of custimzed service.

Our products are widely used are widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, optical image test industries and the field of scientific research, school and laboratory.

QUALITY POLICY

ISO9001, CE, TUV, ROHS, FCC, SCM etc.

OUR CLIENTELE

LG, LENOVO, HUAWEI, EMERSON, SIEMENS, SONY, YKK, PHILIPS, Power Dekor, SEIKO, UNILEVER, Galanz, Colgate, Haire, YOUNGOR, KELON ETC.

PRODUCT PORTFOLIO

Product classification Spectrophotometer/Colorimeter, Colorimeter Accessories, Digital Imaging Test Solution ,Resolution Test Chart, Gloss Meter, Color light box etc

AIM / VISION / MISSION

3nh Vision Focus on color, to become the industry leader in color management field. 3nh adheres to people-oriented, customer first, technological innovation, sustainable development business philosophy to meet customer demand continuously, to create value for customers and to achieve win-win situation and common development.
