    Video Checker Camera Light Box Fish Eye Lens Assessment Cabinet VC-118-S TILO With D65 Light

    Ask Lasest Price
    Brand Name : 3nh-TILO
    Model Number : VC-118-S
    Certification : CE, RoHS
    Price : Please send inquiry
    Payment Terms : T/T
    Supply Ability : 100 Units per Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Video Checker Camera Light Box Fish Eye Lens Assessment Cabinet VC-118-S TILO With D65 Light

    VC-118-S TILO Video Checker Camera Light Box Fish-eye lens Assessment Cabinet with D65 Light


    VC-118-S camera test cabinet is the latest product developed by 3nh. This product can test lens of different angles but using the same chart. Built-in moving sliding table, you can easily move the lens back and forth. VC-118-S equipped with LED lamps with high color rendering index, no flicker, long life and stable color temperature.The user can rotate the light plate in any direction according to the different situations, so as to obtain a more uniform lighting environment.


    VC-118-S camera test cabinet (Figure 1) is mainly consisted of box, lamp control box and bracket.


    Product Specification


    1. Outline Dimension : 1150mm*1045mm*1728mm

    2. Inner Dimension: 1106mm*1001mm*800mm

    Window Dimension: 447mm*700mm

    3. Connector installation plate Dimension: 250mm*150mm

    Connector installation plate consists of : 1 pcs RS232 connector, 1 pcs AV seat, 2 pcs USD connector, 2 pcs Cable base, 2 pcs DC seat, 1 pcs trachea quickfit PM06

    4. Lamp Control Box Dimension (Figure 4): 508mm*248mm*131mm

    5. Operating Temperature: 0~40℃, the relative humidity ≤ 85% (non condensing)

    6. Input Voltage: AC22OV, 50/60Hz (maximum power consumption is 160W)

    7. Net Weight: 130kg


    The standard lamp of VC-118-S is D65 LED light source with 6500K±200K color temperature. The user can configure the light source according to the requirements (like the following table).


    Color temperatureRa
    7500K±200K>91
    6500K±200K>94
    5000K±200K>95
    3000K±200K>95
    2800K±200K>95

    Camera Testing


    VC-118-S camera test cabinet is special designed for camera test to test the lens of different viewing angles . The maximum size of the chart used in this cabinet is 2X ISO 12233 Resolution Test Chart (712mm*400mm). Except this, it is also suitable for other charts to test wide-angle lens and fisheye lens. All the charts are magnetic, and able to be placed in any position of the cabinet according to users’ requirement.
