    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard

    Ask Lasest Price
    Brand Name : 3nh
    Model Number : YH1000
    Certification : CE, TUV, FCC, RoHS, ISO9001
    Price : Please send inquiry
    Payment Terms : T/T
    Supply Ability : 500 Units per Month
    Delivery Time : 2-5 Days
    • Product Details
    • Company Profile

    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard

    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard

    Specification
    Haze Meter 3NH YH1000 Light Transmittance Instrument with ASTM D1003 Standard
    YH1000 haze meter can easily achieve ASTM D1003 non-compensation method, full light transmittance, haze test. Open sample bin can
    be vertically and horizontally tested to accommodate more samples to be tested.The YH1000 haze meter uses a PDF array detector to meet the CIE V(λ)2 degree visual response. The compensation method can be used to measure the light transmittance and haze with
    high precision and repeatability.
    Product Model
    YH1000 Haze Meter
    Optical Geometry
    Transmittance:0/D(Parallel light illumination, diffuse viewing);Conform to the standards: ASTM D1003/1044,GB/T 2410,JJF
    1303-2011,CIE 15.2,JIS K7105,JIS K7361,JIS K 7136
    Characteristic
    The instrument can easily achieve ASTM D1003 non-compensation method, full light transmittance, haze test. Open measuring area for
    vertical and horizontal testing. In glass processing, plastic processing, film, screen processing, packaging and other industries
    are widely used in transmittance,haze detection.
    Integrating Sphere Size
    Φ154mm
    Light Source
    400nm to 700nm, combined LED light
    Spectrophotometric Mode
    /
    Sensor
    The PD array detector, satisfies CIE V(λ)2 degree visual response
    Wavelength Range
    /
    Wavelength Interval
    /
    Semiband Width
    /
    Measurement range
    0~100%
    Measuring Aperture
    Φ20mm/Φ15mm/Φ8mm/Φ4mm(Select a single aperture)
    Sample Size
    Thickness<170mm
    Color Space
    /
    Color Difference Formula
    /
    Other Colorimetric Index
    Haze(ASTM D1003/1044),Transmittance T(ASTM)
    Observer Angle
    Illuminant
    D65,A,C
    Displayed Data
    PASS/FAIL Result
    Measuring Time
    About1.5s
    Resolution
    0.01unit
    Repeatability
    Φ20mm,within 0.15 (After preheating and calibration of the instrument, standard deviation values of standard haze tablets with a
    test haze of about 40 for 30 times were taken at intervals of 5s.)
    Inter-instrument Error
    Φ20mm,with 0.4 (After the instrument is preheated and calibrated, the standard deviation between the standard haze tablet and the
    reference value is tested at an interval of 5s.)
    Dimension
    L*W*H=290X211X511mm
    Weight
    About7.6kg
    Power
    AC 24V, 3A Power adapter power supply
    Illuminant Life Span
    5 years, more than 3 million times measurements
    Display
    7-inch TFT color LCD, Capacitive Touch Screen
    Data Port
    USB, Print serial port
    Data Storage
    Standard 1000 pcs,sample 10000 pcs
    Language
    Simplified Chinese,Traditional Chinese,English
    Operating Environment
    0~40℃(32~104°F)
    Storage Environment
    -20~50℃(-4~122°F)
    Standard Accessory
    Power Adapter, User Guide,Quality Management Software (download from the official website),USB cable,0% calibration box, measuring
    aperture.
    Optional Accessory
    Micro-printer,Test fixture, standard haze sheet, foot switch
    Note:
    The specifications are subject to change without notice.
    Product Description
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    Packing & Delivery
    Standard Export Package
    Company Profile
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3nh is a large-scale manufacturer of color difference meter in China. Its main products series include: TS series grating
    spectrophotometer, YS series grating spectrophotometer (portable / desktop), NS series handheld spectrophotometer, NH series portable colorimeter, NR series handheld colorimeter; Tilo brand light cabinets has a large R & D, production and sales base, and its production and sales is always in the leader for a long time; Sine Image is one brand of the company to offer image test chart, test software and solutions, including the independent R & D and production high-definition iso12233 resolution test chart and other full series of test chart, standard light sources, test software and test solutions etc. Sine Image has a professional image test laboratory. And 3nh also has many domestic innovative technologies for gloss meter, with high, medium and low gloss automatic switching function. It includes large screen economic HG series, large touch screen NHG series with glossy board calibrated function, economic digital YG series.
    Certifications
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    3NH YH1000 Light Transmittance Meter Haze Meter ASTM D1003 Standard
    FAQ
    1. Which models are the equivalent models to YS3060?
    Answer: KONICA MINOLTA CM-2600d, CM-700d and X-rite Ci64, Ci64UV are the equivalent models to 3nh YS3060.
    2. Are you a trader or a manufacturer?
    Answer: We 3nh is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments and
    gloss meters. Our company and factory are located in Shenzhen which is famous for manufacturing. Welcome to visit us!
    3. What's your main market.
    Answer: We sell to the global market.
    4. How long is your delivery time?
    Answer: Generally it is 1-3 working days after the payment confirmed.
    5. What is your payment terms?
    Answer: The payment term is 100% T/T in advance.
    6. What's your minimum order quantity (MOQ)?
    Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.
