Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268

    Buy cheap Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268 from wholesalers

    Buy cheap Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268 from wholesalers
    • Buy cheap Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268 from wholesalers
    • Buy cheap Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268 from wholesalers

    Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268

    Ask Lasest Price
    Brand Name : 3nh
    Model Number : YG268
    Certification : CE, TUV, FCC, RoHs
    Price : Please send inquiry
    Payment Terms : T/T
    Supply Ability : 1000 Units per Month
    Delivery Time : 1-5 Days
    • Product Details
    • Company Profile

    Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268

    3nh yg268 stanliess Steel glossmeter plastic three angle gloss meter with 2000 gu range


    Technical Specification


    ParametersTri-angle Gloss Meter YG268
    Measuring Angle

    20° & 60° & 85°

    Comply with Standard ISO2813, GB/T 9754, ASTM D 523, ASTM D 2457

    Measuring Area20°: 9×10mm, 60°: 9x15mm, 85°: 5×38mm
    Measuring Range20°: 0~2000GU, 60°:0~1000GU, 85°: 0~160GU
    Division Value0.1GU
    Measurement Range Repeatability0-100GU 100-2000GU
    ± 0.2GU ± 0.2%GU
    Measurement StandardConform to the Working Requirements for JJG696 First Class Glossmeter
    Chromaticity ResponseCorresponding with CIE 1931(2°) under CIE C Light Source
    Tolerance±0.2, ±0.2%
    Measuring Time0.1s
    Display SizeTFT 2.3"
    Data PortUSB
    LanguageChinese, English
    Battery1pcs of No.5 dry cell battery more than 10000 times (within 8 hours)
    Dimension160*52*84mm
    Weight350g
    Measuring Mode&Storage

    Basic Mode and Continuous Mode: 15000

    Statistical Mode: 10000

    QA Mode: 10000

    PC SoftwareGQC6 Quality Control Software with QC Report Printing Functions and More Extended Functions
    Operation Temperature0~40℃ (32~104℉)
    Storage Temperature-20~50℃ (-4~122℉)
    Humidity<85% Relative Humidity, No Condensation
    Standard AccessoriesPower Adapter, USB Cable, User Manual, CD (Including QC Software), Calibration Plate
    Optional AccessoriesMini Printer

    Brief Introduction


    YG series gloss meter is independently developed by Shenzhen 3nh Technology Co., Ltd with independent intellectual property, manufactured according to international standard ISO2813 and China standard GB/T 9754. With auto-calibration and high-end QC software, it can meet the first grade requirements of JJG696.


    Now YG268 Tri-angle Gloss Meter has been widely used by our customers all over the world in many industries, like painting, lacquer, ink, coating, leather, paper, printing, plastics, electronics, furnitures, wood, decorating, ceramics, tiles, metals, hardware, marble, electroplating, package, food, cosmetics, pharmacy, cloth, garment, textiles, traffic signage, etc.


    Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268Plastic ISO2813 2000Gu Stainless Steel Gloss Meter 3nh Yg268


    Frequently Asked Questions

    1. Which models are the equivalent models to YG268 Gloss Meter?

    Answer: Our YG268 gloss meter is equivalent to BYK4563 Gloss Meter.
    2. Are you a trader or a manufacturer?
    Answer: We 3nh is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments and gloss meters. Our company and factory are located in Shenzhen which is famous for manufacturing. Welcome to visit us!
    3. What's your main market.
    Answer: We sell to the global market.
    4. How long is your delivery time?
    Answer: Generally it is 1-3 working days after the payment confirmed.
    5. What is your payment terms?
    Answer: The payment term is 100% T/T in advance.
    6. What's your minimum order quantity (MOQ)?
    Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.
