    8mm Caliber 3nh Color Difference Meter Colorimeter With CQCS3 Software

    Ask Lasest Price
    Brand Name : 3nh
    Model Number : NH300
    Certification : CE,RoHs,ISO,etc.
    Payment Terms : T/T,Paypal, etc
    Supply Ability : 1000pcs/month
    Delivery Time : 2 work days
    • Product Details
    • Company Profile

    8mm Caliber 3nh Color Difference Meter Colorimeter With CQCS3 Software

    NH300 8mm Caliber Color Difference Meter Colorimeter with CQCS3 Software


    Brief Introduction:


    With 8mm measurement aperture, NH300 portable colorimeter is the highest cost-effective model which is widely used in fabrics, paper, plastic parts, building materials. The standard configuration software CSCQ3 is able to perform color difference analysis, color difference cumulative analysis, chromaticity index, color sample database management, simulating object color, etc.


    Compare with NH310, the NH300 is cheaper than NH310 Colorimeter and the accuracy is very close. But NH310 with more function when compare with NH300 Colorimeter. In a word, NH300 colorimeter is the basic mode, and NH310 is the high-end mode.Which mode is best are depend on your requirements and budget for this machine.


    Specification:


    NH300 Portable ColorimeterNH310 Portable Colorimeter
    Illuminating/ Viewing Geometery8/d8/d
    Measuring Aperture8mm8mm&4mm
    DetectorSilicon Photoelectric DiodeSilicon Photoelectric Diode
    Color SpaceCIE L*a*b*C*h; CIE L*a*bCIE L*a*b*C*h; CIE L*a*b, CIEXYZ,CIE RGB,CIEL*u*v* CIEL*C*h Yellowness & Whiteness Color Fastness
    Color Difference Formula△E*ab △L*a*b △E*C*h△E*ab △L*a*b* △E*C*h* △ECIE94 △Ehunter
    Light SourceD65D65 D50 A
    Light Source DeviceLED blue light excitationLED blue light excitation
    Errors Between Each Equipment≤0.40ΔE*ab≤0.40ΔE*ab
    Storage100pcs standards 20000pcs samples100pcs standards 20000pcs samples
    RepeatabilityStandard deviation within ΔE*ab 0.07
    Average of 30 measurements of standard white plate
    Standard deviation within ΔE*ab 0.06
    Average of 30 measurements of standard white plate
    Weight500g500g
    Dimension205×70×100 mm205×70×100 mm
    Power sourceRechargeable lithium-ion battery 3.7V@3200mAhRechargeable lithium-ion battery 3.7V@3200mAh
    Lamp Life5 years, more than 1.6 million measurements5 years, more than 1.6 million measurements
    Charging Time2 hours (first time 8 hours--100% electricity2 hours (first time 8 hours--100% electricity
    Measurement Times Before RechargingMore than 3000 timesMore than 3000 times
    Operating Temperature/Humidity Range-10~40℃, relative humidity 0~85% with no condensation-10~40℃, relative humidity 0~85% with no condensation
    Data InterfaceUSBUSB
    Extended Aperture (optional)/Φ8mm extended aperture, available for measuring concave surface
    Printer (optional)Miniature thermal printerMiniature thermal printer



    Application:


    3nh colorimeter are widely used in plastic, metal, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, automotive, toy...industries.
