    High Precision Portable Hunter Lab Spectrophotometer YS3060 Equal To CM-2600D Chroma Meter

    High Precision Portable Color Spectrophotometer YS3060 Equal to CM-2600D Chroma Meter


    Brief Introduction:


    YS3060 grating spectrophotometer adopts bluetooth and USB dual modes for wider user. YS3060 spectrophotometer also with SCI & SCE double measuring data, which also with 4mm and 8mm aperture. Special UV light make YS3060 spectrophotometer more accuracy and easy to operating. YS3060 spectrophotometer also with extended PC software which will enable it be a good partner for colorist and color QC management.


    Specification:


    Model

    Items

    YS3060YS3020YS3010
    Optical GeometryReflect: di:8°, de:8°(diffused illumination, 8-degree viewing angle)
    Integrating Sphere Size48mm
    Light SourceCombined LED Light, UV LightCombined LED Light
    Spectrophotometric ModeConcave Grating
    Sensor256 Image Element Double Array CMOS Image Sensor
    Wavelength Range400-700nm
    Wavelength Interval10nm
    Semiband Width10nm
    Measured Reflectance Range0-200%
    Measuring ApertureDual Aperture: 10mm/8mm & 5mm/4mmCustomized Aperture: 8mm/4mm/1×3mmSingle Aperture: 8mm/10mm
    Specular ComponentSCI&SCE
    Color SpaceCIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB
    Color Difference FormulaΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00v, ΔE(Hunter)
    Other Colorimetric Index

    WI(ASTM E313, CIE/ISO, AATCC, Hunter),

    YI(ASTM D1925, ASTM 313),TI(ASTM E313, CIE/ISO),

    Metamerism Index MI, Staining Fastness, Color Fastness, Color Strength, Opacity, 8° Glossiness

    Observer Angle2°/10°
    IlluminantD65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12D65, A, C, D50, D55, D75, F2, F7, F11D65, A, C, D50
    Displayed DataSpectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset
    Measuring Time2.6s
    RepeatabilityMAV/SCI: ΔE*≤0.03MAV/SCI: ΔE*≤0.05MAV/SCI: ΔE*≤0.06
    Inter-instrument ErrorMAV/SCI: ΔE*≤0.15MAV/SCI: ΔE*≤0.2MAV/SCI: ΔE*≤0.4
    Measurement ModeSingle Measurement, Average Measurement
    Locating MethodCamera View Finder Locating
    BatteryLi-ion battery. 5000 measurements within 8 hours
    DimensionL*W*H=184*77*105mm
    Weight600g
    Illuminant Life Span5 years, more than 3 million times measurements
    Display3.5-inch TFT color LCD, Capacitive Touch Screen
    Data PortUSB, Bluetooth 4.0USB
    Data StorageStandard 2000 Pcs, Sample 20000 Pcs
    LanguageEnglish, Chinese
    Operating Environment0~40℃, 0~85%RH (no condensing), Altitude < 2000m
    Storage Environment-20~50℃, 0~85%RH (no condensing)
    Standard AccessoryPower Adapter, Built-In Li-ion Battery, User Guide, PC Software, White and Black Calibration Cavity, Dust Cover
    Optional AccessoryMicro Printer, Powder Test Box
    Notes: The specifications are subject to change without notice.

    Application Industry:


    Grating spectrophotometer can easily achieve color transferring , and be used as a precision instrument for color matching system. It's widely used in plastics, electronics, painting, ink, textile and garment, printing and dyeing, printing paper, automotive, medical, cosmetics and food industries, scientific research institutes, schools and laboratories.
